US Tarp Pull Style Tarping System with 97" Wind Deflector and Rear Pull Bar

The pullstyle kit features a spring-loaded axle so you can manually pull your tarp out and let the roller pull it back in, sometimes called a "window shade" system because of its semi-automatic roll-up style. When ordering a pullstyle kit, we will need to know your exact outside width where the axle is being mounted, because it is pre-cut and pre-loaded to fit your exact truck.

• Covers up 26' with standard tarps or 20' with flaps
• Aluminum extruded 3" roller bar
• Machined aluminum end caps and the heaviest spring for the application in the industry
• Tarp sold separately. Order tarp with kit an kit will ship preassembled, tarp mounted, and spring pre-loaded to save hours in installation
• NOTE: Tarps ordered for use with this system should measure at least 4" less than the width of your mounted axle
• Includes rear pull bar

Installing Pull Rope

• Attach the free end of the Pull Rope to the center of the Rear Pull Bar, through the grommet, with cut end facing upwards. Cut rope to desired length, and tie a knot.
• Mount two J-hooks, with the supplied self-tapping bolts, opposing each other near the rear of the dump (typically on the gate) to secure the Pull Rope in the covered position.
• Mount two J-hooks with the supplied self-tapping bolts oppoting each other near the front of the dump to secure the Pull Rope in the uncovered position.

Please feel free to Contact Us with any Questions. Thank You!
